| CONSTRUCTION FEATURES |
 |
| Dial Size |
: |
100mm, 150mm & 250mm |
| Accuracy |
: |
± 1.6% of full scale |
| Case & Bezel (IP-65) |
: |
SS 304, Snap Action Bayonet type
|
| Movement |
: |
SS 304 |
| Pressure Element |
: |
SS 316 |
| Socket |
: |
SS 304 / SS 316 |
| Dial |
: |
Aluminum white painted with
270 degree black scale markins |
| Pointer |
: |
Al. / Brass with black finish |
| Window |
: |
Acrylic / Safety glass |
| Blow Out Protection |
: |
On top at 0.6 Kg/cm2 |
| Over Load Protection |
: |
115% of f.s.d.
|
| Joints |
: |
Argon arc welded |
| Mounting |
: |
Stem (Bottom), Surface, Panel Mounting,
Flush Panel ( Bracket Type) |
| Connection |
: |
3/8" / 1/2" BSP / NPT |
| Scale Range |
: |
Pressure up to 15000 PSI to 80000 PSI |
|
| MODEL OPTION |
|
| SP |
: |
All SS Models with Heavy Duty Parts. |
| |
|
|
| APPLICATION |
|
| Specially in High Pressure Application. Hydraulic Pressure, Hydralic Power Packs,High Pressure Pumps, Testing of High Pressure Devices. |
|
